10 W 6.5" round wall or ceiling surface mount loudspeaker, metal

582423 | 10 W 6.5

The loudspeaker DL-A 10-165/T-EN 54 for voice alarm made of powder-coated metal in white with high degree of efficiency and a high-quality 200 mm broadband loudspeaker chassis. DL-A 10-165/T-EN 54 can be installed on ceiling and walls, where recessed mounting is not possible. Flat and elegant design for unobtrusive installations provided with a metal back plate. The loudspeaker is equipped for highest security requirements with a ceramic terminal and a thermal fuse. The Chassis is protected against moisture by impregnation. The DL-A 10-165/T EN 54 offers a powerful sound besides the high safety standard.

Part-No.:
582423

Technical Data

Rated Power
10 W
Rated power handling
Transformer power taps
Rated impedance
Kennschalldruck 1W / 1m
Kennschalldruck 1W / 4m
Kennschalldruck 6W / 4m
SPL 1 W / 1 m (Double)
dB
SPL Pmax / 1 m
dB
SPL Pmax / 1m (Double)
dB
Sensitivity EN 54-24, 1 W / 1 m
90,7 dB
Sensitivity EN 54 (double)
dB
Sensitivity EN 54-24 max (double)
dB
Sensitivity
dB
Sensitivity EN 54-24, max 1 m
100,7 dB
Transmission range
290 Hz ... 23400 Hz
Sensitivity EN 54-24 1 W / 1 m_comp
Sensitivity EN 54-24, 1 W / 4 m_comp
Sensitivity EN 54-24 6 W / 4 m_comp
Impedance
Ω
Sensitivity
mV
Sensitivity
Dispersion angle
Ambient temperature
-20 °C ... 80 °C
Storage temperature
Air humidity
Air humidity
Type of protection
Housing
Material
Color
white, similar to RAL 9010

Weight
Weight
approx. 1,3 kg

Cut-out size
Connection lead
Dimensions
Ø: 170 mm D: 75 mm


SPL Pmax / 1m
Rated voltage
Output power *8
Approval
