Features
- Connection to RS485 dual interface
- Capacitive control panel
- Optional for non-redundant or redundant connections
- Graphic display with 6 lines of 20 characters each
- Additional text is transferred from the FACP
- 4 buttons for operating the display (scroll up/down, slide right/left)
- 3 buttons for operating the buzzer: off, test, and history
- 1 button to confirm selection for special functions
- 4 LED common displays (operation, alarm, fault, shutdown)
- 6 programmable buttons for macro operation that control a configurable series of operating procedures, e.g. Detector Zone-1 to Detector Zone-10
- 5 programmable individual displays
- Acoustic signaling
- History function
- Direct connection to FACP via RS485 interface - max. 1 device
- Connection via ADP4000 - max. 16 devices
