Features
- Single loop panel (system supports up to 127 digital loop addresses in total)
- Integrated esserbus-PLus (loop powered)
- Short circuit and open circuit tolerant loop operation with stub cable exits
- Operation of bus-supplied, synchronously controlled alarm generators (optical/acoustic/voice) in different alarm areas via esserbus-PLus powered loop technology
- Length of the loop circuit (esserbus) up to 3.5 km
- Up to 127 esserbus devices (fire detectors or manual call points)/group
- Up to 32 esserbus transponders
- Up to 30 IQ8Quad detectors with integrated sounders
- Up to 20 IQ8Alarm / IQ8Alarm Plus sounder
- Operation of ATEX approved detectors (intrinsically safe) for potentially explosive areas
- Optimized commissioning, maintenance and operation
- Easy configuration and programming of the FACP functions via display
- 4 relays, programmable, not monitored, potential-free, max. 30 V DC/2 A or 60 V DC/1 A
- 2 outputs for connection to acoustic and optical sounders according to EN 54-13 (each 24 V DC/max. 500 mA)
- 1 interface to a transmission unit (TU) for Fire alarm routing equipment (FARE) (12 V DC/max. 200 mA)
- 1 interface to a transmission unit (TU) for fault reports (12 V DC/max. 200 mA)
- 1 standard interface solution for fire control type C acc. DIN EN 54-2
- RS485 for connection of fire brigade control panel and fire brigade graphic annunciator
- 1 output UBext 24 V/0.5 A, for the voltage supply of external devices
- 72 hour emergency bypass (depending on configuration)
- Integrated detector groups individual display
- Function "delay the transmission" (according to DIN VDE 0833-2, to avoid false alarms, delay/investigate)
- Function "two-message dependency" (according to DIN VDE 0833-2, to avoid false alarms), alternatively programmable as alarm caching, multi-group dependence or multi-detector dependency
- Operating panel with alphanumerical display
- Large LCD display with 8 rows x 40 characters
- Alarm counter for up to 10,000 trips
- Event memory for up to 10,000 events
