Features
- 8 sensor groups with up to 30 sensors in each sensor group (conventional panel supports up to 240 conventional devices in total)
- Large LCD display with 8 rows x 40 characters
- Integrated sensor group single display
- Optimized commissioning, maintenance and operation
- Simple configuration and programming on the keypad
- Four relays, freely programmable, non-monitored, potential free, max. 30 V DC / 2 A or 60 V DC / 1 A
- 2 outputs for connecting acoustic or optical sounders according to EN 54-13 (29 V DC/ max. 500 mA)
- 1 interface to a transmission unit for fire alarm routing equipment (FARE) (12 V DC / max. 200 mA)
- 1 interface to a transmission unit for fault warnings (12 V DC / max. 200 mA)
- 1 standard interface extinguisher for fire control system type C according to DIN EN 54-2
- RS485 for connecting to fire brigade operating panel and fire brigade display panel
- 1 output UBext 29 V / 0.5A, for power supply of external bus users
- 72 h emergency current bridge
- “Delay of relaying” function (PM operating mode according to DIN VDE 0833-2 for preventing false alarms, delay / verify)
- “2-detection dependency” function (TM operating mode according to DIN VDE 0833-2 for preventing false alarms), alternatively programmable as intermediate alarm storage or 2-zone dependency between the detector zones
- Operating panel with alphanumerical display
- Large LCD display with 8 rows x 40 characters
- Alarm counter for up to 10,000 trips
- Event memory for up to 10,000 events
